描述

5X00070G04

可編程控制器工作時控制回路中各元件并不需要實際接線，而是由PLC指令的執行來代替。指令執行結果會送到PLC的輸出點，由輸出點與外接電源和負載等構成回路，達到控制負載的目的。PLC輸出方式有繼電器輸出、晶體管輸出和晶閘管輸出三種，F(xiàn)X2N-48MR采用的是繼電器輸出方式，圖5所示為其典型的輸出回路接線。

FX0N的EEPROM用戶存儲器容量為2000步?；局噶钣?0條，步進指令2條，應用指令36種51條。FX0N有500多點的輔助繼電器，128點狀態寄存器，95個定時器和45個計數器（其中高速計數器13個）還有大量的數據寄存器，76點指針用于跳轉，中斷和嵌套。FX0N有較強的通信功能，可與內置RS－232C通信接口的設備通信，如使用FX0N－485APP模塊，可與計算機實現1：N（最多8臺）的通信。FX0N還備有8位模擬量輸入輸出模塊（2路輸入，1路輸出）用以實現模擬量的控制。由于FX0N體積小，功能強，使用靈活，特別適用于由于安裝尺寸的限制而難以采用其他PLC的機械設備上。
