描述
??? 根據繼電器電路圖設計PLC的外部接線圖和梯形圖時應注意以下問題。
●應遵守梯形圖語言中的語法規定。由于工作原理不同，梯形圖不能照搬繼電器電路中的某些處理方法。例如在繼電器電路中，觸點可以放在線圈的兩側，但是在梯形圖中，線圈必須放在電路的最右邊。
●適當?shù)姆蛛x繼電器電路圖中的某些電路。設計繼電器電路圖時的一個基本原則是盡量減少圖中使用的觸點的個數，因?yàn)檫@意味著成本的節約，但是這往往會使某些線圈的控制電路交織在一起。在設計梯形圖時首要的問題是設計的思路要清楚，設計出的梯形圖容易閱讀和理解，并不是告別在意是否多用幾個觸點，因?yàn)檫@不會增加硬件的成本，只是在輸入程序時需要多花一點時間。
●盡量減少PLC的輸入和輸出點。PLC的價格與I/O點數有關，因此輸入、輸出信號的點數是降低硬件費用的主要措施。在PLC的外部輸入電路中，各輸入端可以接常開點或是常閉點，也可以接觸點組成的串并聯電路。PLC不能識別外部電路的結構和觸點類型，只能識別外部電路的通斷。
●時間繼電器的處理。時間繼電器除了有延時動作的觸點外，還有在線圈通電瞬間接通的瞬動觸點。在梯形圖中，可以在定時器的線圈兩端并聯儲器位的線圈，它的觸點相當于定時器的瞬動觸點。
●設置中間單元。在梯形圖中，若多個線圈都受某一觸點串并聯電路的控制。為了簡化電路，在梯形圖中可以設置中間單元，即用該電路來控制某存儲位，在各線圈的控制電路中使用其常開觸點。這種中間元件類似于繼電器電路中的中間繼電器。
●設立外部互鎖電路?？刂飘惒诫妱?dòng)機正以轉的交流接觸器如果同時動作，將會造成三相電源短路。為了防止出現這樣的事故，應在PLC外部設置硬件互鎖電路。
●外部負載的額定電壓。PLC雙向晶閘管輸出模塊一般只能驅動額定電壓AC 220V的負載，如果系統原來的交流接觸器的線圈電壓為380V，應換成220V的線圈，或是設置外部中間繼電器。
產品承諾：
保?證?全新原裝進口,
保?證?安全準時發貨，
保?證售后服務質量，
優勢價格，大量現貨。
主營DCS系統配件
機器人系統配件
大型伺服系統配件
品牌：ABB???,AB??,GE,FOXBORO,本特利，英維思，伍德沃德，西屋，瑞恩，施耐德，西門子，摩托羅拉，安川。力士樂。ACSO，橫河等進口品牌。 專業銷售進口DCS? PLC系統備件模塊
Triconex?Siemens?Yaskawa?ABB?GE?Ovation?AB?Foxboro?Motorola?Schneider?XYCOM?KUKA ? 專業銷售進口DCS? PLC系統備件模塊 15天包退換 一年質保 大量現貨? 國內實力庫存商家
