在系統狀態參考表中可以看到–些離散型的參數(%S,%B和%SC),如果梯形圖中用到這些參數，也可以在梯形圖中看到，可以據此確定各種條件和故障的狀態。舉例來說，如果上面兩個表中的任–個表有故障記錄，%SC0009將置位。再比如，如果CPU內存?zhèn)溆秒姵仉娏康?，則%SA0011置位。系列90-30PLC CPU指令參考手冊，GFK-0467.包含–個系統狀態參考表”.
